Switch - On/Off Switch

Switch - On/Off Switch

M40218
  • On/off switch for micromotors
  • For products: FDK1020, K1080CE, K1070CE, K1090CE & FDK1050

The replacement of the ON/OFF switch is very simple.

1. Remove the 4 feet from the control box

2. Remove the bottom cover

3. Pull out circuit board to expose wiring

4. Unplug the white connectors.

5. Push out the switch from the back to the front of the unit to remove

6. Snap new switch into place from the front

7. Connect the white connectors marked "POWER" and "POWER SWITCH" to respective connectors on the main board

8. Reassemble
£5.95
EACH

Quantity Discounts

£5.95 when you buy 1
£5.65 when you buy 2 or more
1 In Stock More available via backorder

Availability of stock is limited to number shown. Additional quantities are available via backorder and will be fulfilled and shipped separately when restocked.
