Horotec Case Back Rectangular (06.530)

Horotec 06.530 - Swiss Made - Thread Ø6mm (M6)Set of 6, varying size rectangular dies for fitting snap-on case backs or rectangular glasses. All dies compatible with all Horotec screw-on presses (plus also Bergeon & our Swiss Style Presses).

• Ø6mm thread
• Reinforced metal core to handle extreme pressure
• Delrin, strong non marking material
• Sizes given are the outer edges

Dimensions: Length Ext. x Length Int. x (width x height)

• 24 x 13 x (13 x 13mm)
• 29 x 18 x (16 x 13mm)
• 34 x 23 x (19 x 13mm)
• 39 x 28 x (22 x 13mm)
• 44 x 33 x (25 x 13mm)
• 49 x 38 x (28 x 13mm)

Wall is 5.5mm thick with a 105 degree inner slopping chamfer
