Hermle 1171.890S (Seconds)

Hermle 1171.8908 day triple chime, cable driven clock movement with seconds

• 8 day
• Strike: Triple chime
• 9 Tubular strike
• Plate size: 152 x 220mm
• Anchor escapement, automatic beat
• Length A: 55.5mm (Plate to hand nut thread, see web diagram)
• Length B: 48mm (Shaft length, see web diagram)
• Mounting depth: 270mm (tip of handshaft to back of movement)
• Cable driven
• Pendulum length identification is stamped on the movement (pendulums supplied separately)
• Pendulum length in brackets
• Seconds feature
• Supplied with automatic night shut off
• Supplied with pendulum leader (our code L9604)

Hermle state that in this combination, “S” means seconds featureAvailable separately:

• 3.5Kg weight: H38196
• 8.4Kg weight: W46180
• Weight shell: H46185
• Moon phase transmission wheel: H52227 (required if using movement with moon phase dial)
