Hermle 1151.053H (Dead Beat, High Bridge)

Hermle 1151.053H


8 day triple chime, weight driven clock movement with high bridge, dead beat


  • 8 day
  • Strike: Triple chime
  • Hammers: 12 behind
  • Plate size: 120 x 120mm
  • Anchor escapement, dead beat
  • Length A: 53.2mm (Plate to hand nut thread, see web diagram)
  • Length B: 48.5mm (Shaft length, see web diagram)
  • Mounting depth: 200mm (tip of handshaft to back of movement)
  • Weight driven
  • Pendulum length identification is stamped on the movement (pendulums supplied separately)
  • Pendulum length in brackets
  • High bridge
  • Supplied with chime and strike shut off (silence) lever

Hermle state that in this combination, “H” means high bridge


Available separately:

  • 2Kg weight: HERE00502700
  • 3.3Kg weight: H38202
  • Weight shell: H38201
  • Gong: H28888
