18 x 28mm (Gorge No.11)
Gorge Swiss Made Platform Escapement
Plate Size: 18mm x 28mm
Dimensions:
Plate Size: 18mm x 28mm
Dimensions:
- Width 18mm
- Length 28mm
- Overall height 19.25mm (distance from the top of the balance to the end of the bracket holding the pinion)
- 8 Leaf Escape Wheel
- Alt. Frequency 18000 Alt/h
- Pallet wheel rotation: Right
- Finely tumbled surface
- Position of pinion: 9mm from 3 sides of the base plate
- Depth of pinion: 4.6mm max below the base plate
- Escape Wheel Drop 8.75mm (distance from the plate to the end of the bracket holding the pinion)
- Escape Wheel Teeth Module 0.25
